OPA742 Series
1 Watt Light Spot on
OptoTherm Linear Heat Spreader with Lens
OPA742 Series
?
?
1 watt LED on round substrate
Mono-color per strip (Blue, Green, Red, Yellow, White)
?
?
?
Component beam angle option 23°
Universal connector (Tyco 2-292173-2 mates with 173977-2)
RoHS Compliant
Product Photo Here
OPA742_ (23° Beam Angle)
The OPA742 Series are designed for areas where lighting intensity and reliability
are essential. The light beam angle of 23° is ideal for illuminating areas close or a long distances from the device
while requiring minimal space. A High Performance Heat Spreader (HPHS) is used to ensure the best heat
dissipation of any light assembly in the industry.
For custom colors and design contact your OPTEK representative.
Electrical / Optical Characteristics: T A =25°C, I F =350mA
Part Number
OPA742Y23
OPA742B23
OPA742G23
OPA742R23
OPA742W23
Typical Forward Voltage (V)
2.5
3.6
3.6
2.5
3.6
Luminous Flux (lm)
22
8
41
30
41
Beam Angle
23°
Color
Yellow
Blue
Green
Red
White
Dominant Wavelength
587 nm
470 nm
530 nm
625 nm
6,500°K
+ Volt-
Ground
OPA742_
See OVSP_BCR4 for
component specifications
RoHS
DO NOT LOOK DIRECTLY AT LED
WITH UNSHIELDED EYES OR
DAMAGE TO RETINA MAY
OCCUR.
OPTEK reserves the right to make changes at any time in order to improve design and to supply the best product possible.
OPTEK Technology Inc. — 1645 Wallace Drive, Carrollton, Texas 75006
Phone: (972) 323-2200 or (800) 341-4747 FAX: (972) 323-2396 visibleLED@optekinc.com www.optekinc.com
Issue A.2 09/08
Page 1 of 1
